US Mags Cten Wheel 5x5 (5x127) - 1988-1998 Chevy/GMC C1500 OBS

$472.00 USD
$472.00 USD
Shipping calculated at checkout.
Size
Backspacing
Finish

US Mags Cten wheels, drilled 5x5 (5x127) for the 1988-1998 Chevy/GMC C1500 OBS truck. Choose your size, backspacing / offset and finish from the options above; full specs for every part number are in the table below.

Sizes: 18x8, 18x9.5, 20x8.5, 20x10, 22x8.5, 22x10.5
Finishes: Chrome Plated, Matte Gunmetal Milled

Construction: One-piece cast aluminum (monoblock) construction.

Fitment: Fits 1988-1998 Chevy/GMC C1500 2WD (5x5 / 5x127 bolt pattern). Center bore 78.1mm. K1500 4x4 (6x5.5) and 2500/3500 (8x6.5) are not this listing.

Specifications

Part # Size Finish Offset Backspacing Load Rating Weight Lip Depth Cap Part #
U12718807345 18x8 Chrome Plated +1mm 4.54 in 1,900 lbs 29 lbs 2.7 in 1014-09-06P
U12718957352 18x9.5 Chrome Plated +1mm 5.29 in 1,900 lbs 30 lbs 3.95 in 1014-09-06P
U12720857350 20x8.5 Chrome Plated +7mm 5.03 in 1,900 lbs 32 lbs 2.83 in 1014-09-06P
U12920857350 20x8.5 Matte Gunmetal Milled +7mm 5.03 in 1,900 lbs 32 lbs 2.83 in 1014-09-06GD
U12720007355 20x10 Chrome Plated +1mm 5.54 in 1,900 lbs 32 lbs 3.91 in 1014-09-06P
U12920007355 20x10 Matte Gunmetal Milled +1mm 5.54 in 1,900 lbs 32 lbs 3.91 in 1014-09-06GD
U12722857347 22x8.5 Chrome Plated +1mm 4.79 in 1,900 lbs 35 lbs 3.1 in 1014-09-06P
U12922857347 22x8.5 Matte Gunmetal Milled +1mm 4.79 in 1,900 lbs 35 lbs 3.1 in 1014-09-06GD
U12722057357 22x10.5 Chrome Plated +1mm 5.79 in 1,900 lbs 37 lbs 4.18 in 1014-09-06P
U12922057357 22x10.5 Matte Gunmetal Milled +1mm 5.79 in 1,900 lbs 37 lbs 4.18 in 1014-09-06GD

Specs from US Mags (Wheel Pros). All wheels: 5x127 (5x5") bolt pattern, 78.1mm center bore.
